Infrared System |
|
Detector Type | Uncooled VOx FPA |
Detector Resolution | 640 x 512 px |
Operating Wavelength | 8 ~ 14 μm |
Pixel Pitch | 12 μm |
Frame Rate | 50 Hz |
Sensitivity | ≤ 40 mk |
False Color | 8 types including White Hot/Black Hot/Rainbow/Metal/Green Hot |
Focusing Method | Electric |
Focus Range | 10 m ~ ∞ |
Lens Focal Length | f=75 mm, F#1.0 |
Field of View (FOV) | 5.85°×4.68° |
Digital Zoom | 1~8x |
Detection Distance | Human (1.7×0.5 m): 4000 m |
Vehicle (3.0×1.5 m): 7000 m |
Recognition Distance | Human (1.7×0.5 m): 1000 m |
Vehicle (3.0×1.5 m): 2800 m |
Visible Light System |
|
CMOS Type | Ultra-low Illumination CMOS |
Resolution | 2560×1440 px |
CMOS Size | 1/2'' inch |
Lens Focal Length | f=100 mm |
Frame Rate | 50 Hz |
Zoom | Digital Zoom 1x-8x |
Detection Distance | Human (1.7×0.5 m): 4500 m |
Vehicle (3.0×1.5 m): 9000 m |
Recognition Distance | Human (1.7×0.5 m): 2000 m |
Vehicle (3.0×1.5 m): 5000 m |
Fog Penetration Mode | Manual (Level 1-4)/Auto |
Electronic Image Stabilization | Level 1-3 |
Laser Ranging |
|
Wavelength | 1535 nm |
Ranging Range | ≥6 km |
Accuracy | ±1 m |
Efficiency | >98% |
Display |
|
Screen | 2×0.39'' inch OLED |
Resolution | 1024×768 px |
Eyepiece Magnification | 15× |
Image Mode | Thermal Imaging, Visible Light, Picture-in-Picture (2 types), Fusion. ≥25 fps |
Interactive Info Display | Time, Battery Level, Channel, Azimuth, Elevation, Coordinates, etc. |
Image Adjustment | Brightness, Contrast, Detail Enhancement (Level 1-5), etc. |
Interaction |
|
Beidou | ≤ 5 m (CEP). Equipped (L1+L5) for self-positioning and target positioning |
Wi-Fi | Optional |
Electronic Compass - Azimuth | 0-360° ±0.5° |
Electronic Compass - Elevation | ±90° ±0.2° (Scale Mark Display) |
Photo & Video | One-touch Photo & Video Capture |
Storage | Built-in emmc Storage, 32 GB |
Data Transmission | Image & Video: USB2.0/UVC Video Interface |
Tripod Compatibility | 1/4 inch Standard Tripod Mount |
Power Supply |
|
Battery | 7.2 V 8000 mAh (4×18650 Li-ion Batteries) |
Average Power Consumption | ≈ 5.5 W |
Average Usage Time | ≥6 h |
Environment |
|
Protection Class | IP66 |
Operating Temperature | -30°~+55° |
Storage Temperature | -40°~+60° (No Condensation) |
Anti-interference Level | Compliant with GB/T17626.2-2018 Level 3 |
Dimensions |
|
Size | 241 mm (Length) × 242 mm (Width) × 97 mm (Height) |
Weight | ≈ 2.4 Kg (Including Battery) |
|
|
|
