Product Model:
NTIRL3 Advanced Hand-held Laser Designator ≥ 2000m
Product Overview:
The NTIRL3 Advanced Handheld Laser Designator is a critical force multiplier for modern artillery and missile systems. This robust system generates a precise laser spot for guiding munitions onto targets with pinpoint accuracy. It integrates a powerful 1064nm laser designator, a high-resolution thermal imaging channel, and an eye-safe laser rangefinder within a single, portable unit. Designed for forward observers and special operations teams, the NTIRL3 ensures mission success in the most challenging desert and cold-weather environments.
WhatsApp: +43 67844091116
Tel: +86 18608017948(WeChat)
E-mail: marketing@newtron-tech.com
Key Feature
Intergral Laser designator, IR thermal camera, day camera, eye-safe LRF, DMC, GPS
Advanced laser guidance capabilities
Real-time target acquisition and target coordinate calculation
Target image and data storage memory
Long-range performance
All-weather target locator for missile force, dust-proof border defense surveillance systems
Low-power military target acquisition (≤1.5W peak), energy-saving night sight for border patrol
Application Scenarios
Missile force, artillery targeting systems, infantry surveillance gear, scout and special units
Security border defense systems
Military target acquisition for commanders
Night sight target acquisition, tactical target location equipment
Scout target locator, special forces night sight
Specifications
Table1: Basic Parameters
Thermal Channel |
IR detector type | 1024x768, LWIR, Uncooled detector |
Digital zoom | x1.0 ~ x8.0 |
Field of view | ≥ 6.2°x5° |
Recognition range | To Vehicle: 2km |
Day Channel |
TV detector type | 1920x1080, HD CMOS |
Display | 1280x1024, HD OLED |
Digital zoom | x1.0 - x8.0 |
Field of view | 7.8°x6.3°(WFOV)~2.7°x2.1°(NFOV) |
Recognition range | To Vehicle: 5km |
Laser Rangefinder |
Wavelength | 1550±20nm, eye-safe |
Accuracy | ±5m |
Range | To Vehicle: 5km |
Laser Designator |
Wavelength | 1064±10nm |
Beam divergence | ≤ 0.3mrad |
Average energy optional output | 40~60mJ / 60~80mJ / ≥80mJ |
Accuracy |
GPS accuracy | CEP&PE ≤ 10m |
DMC accuracy | RMS ≤ 0.5° |
Storage & Battery |
Storage ability | ≥4h AVI audio and video, ≥10000 BMP photos |
Continuous working time (@25℃) | ≥ 4h |
Physical & Environmental Adaptability |
Dimension | ≤ 295 x 230 x 130 mm |
Weight | ≤ 4.6kg |
